Descripción
Características técnicas
| SKU | EPDUM20040X |
|---|---|
| Nominal Voltage | 250V |
| Frequency | 50/60Hz |
| Phase | Single phases |
| Plug Type | IEC60309 (32A 250VAC 2P+E) / Legrand |
| Power Cord Spec | 3 x 2.5mm² x 3 meters |
| Max Input Current | 32A |
| Rated Input Current | 32A |
| Wiring Style | L-N wiring |
| Power Capacity | 7000W |
| Nominal Voltage | 250V |
| Max Output Current | 32A |
| Output Connections | 20 x IEC 320 C13 ; 4 x IEC 320 C19 |
| Outlet Locking | Yes |
| Circuit Overload Protection | None |
| Surge Suppression | None |
| Input/Phase Metering | Yes |
| Outlet Metering | No |
| Breaker Status Monitoring | Yes |
| Metering Accuracy | +/- 1% |
| Outlet Switching | No |
| Environmental Monitoring | Temperature, Humidity, (Door contact, Water leakage, Smoke status customizable with external sensor box) |
| Monitoring Parameters | Voltage (V), Current (A), Active Power (kW), Apparent Power (kVA), Energy (kWh), Power Factor, Breaker status |
| Access | SNMP (V1,V2c,V3), HTTP/HTTPS, Telnet, Modbus-RTU |
| Authentication | N/A |
| Alerts | Voltage, current, (temperature, humidity, door status, water leaking, smoke) optional |
| Service | TFTP, SMTP |
| Daisy-chain | 1 master 3 slaves |
| Product Dimensions (HxWxD) | 1829.0*56.0*56.0mm |
| Box Dimensions (HxWxD) | 1950.0*76.0*76.0mm |
| Product Weight | 6,17 |
| Box Weight | 8 |
| Mounting Style | Rear buttons mounting |
| Mounting Distance | None |
| Operating Temperature | -10~45℃ |
| Operating Relative Humidity | 5%~95% |
| Operating Elevation | 0~3000 meters |
| EMC Verification | EN55022, EN61000 |
| Safety Verification | IEC/EN 60950, IEC/EN 62368 |
| Environmental Verification | RoHS 2.0 |
| Característica 1 | PDU monitorable de 32A. |
| Característica 2 | Indicador de estado LCD/RGB dealta definición. |
| Característica 3 | Módulo de toma de salida reemplazable. |
| Característica 4 | Diseño de estructura compacta. |
| Característica 5 | Controlador hot swap sin tornillos. |
| Característica 6 | Tomas de seguridad. |
| Característica 7 | Protocolos de comunicación avanzados. |
| Característica 8 | Monitoreo integral del ambiente del rack. |
| Característica 9 | Opciones de instalación flexibles. |
| Característica 10 | Conexión en cascada. |
| Característica 11 | Monitoreo vía Browser |
| Dimensiones del Producto con Embalaje — Largo (cm) | No disponible |
| Dimensiones del Producto con Embalaje — Ancho (cm) | No disponible |
| Dimensiones del Producto con Embalaje — Alto (cm) | No disponible |
| Peso del Producto incluído el Embalaje — Peso (kg) | No disponible |
